Overview of AWWA C213 Fusion Bonded Epoxy (FBE) Coated Spiral Weld Pipe

The AWWA C213 FBE Coated Spiral Weld Pipe is a high-performance steel pipe used for water transmission, wastewater systems, oil & gas pipelines, and industrial applications. The fusion bonded epoxy (FBE) coating provides exceptional corrosion resistance, mechanical protection, and chemical durability, making it an ideal choice for buried pipelines, high-pressure systems, and aggressive environments.

Key Features of AWWA C213 FBE Coated Spiral Weld Pipe

✔ Spiral Submerged Arc Welded (SSAW) steel pipe
✔ AWWA C213-compliant fusion bonded epoxy (FBE) coating
✔ High resistance to corrosion, abrasion, and chemical exposure
✔ Available in diameters ranging from 6 inches to 144 inches (150mm to 3658mm)
✔ Complies with AWWA C213, API 5L, ASTM A252, and GB/T9711 standards
✔ Ideal for potable water, wastewater, and oil & gas applications

This guide will cover manufacturing processes, applications, price trends, suppliers, and quality standards for AWWA C213 FBE Coated Spiral Weld Pipes.

Top AWWA C213 FBE Coated Spiral Weld Pipe Manufacturers in 2025

Choosing a reliable manufacturer ensures high-quality materials, precise coating application, and compliance with AWWA standards. Here are some of the leading AWWA C213 FBE Coated Spiral Weld Pipe manufacturers:

1. Cangzhou Spiral Steel Pipes Group Co., Ltd

✔ 27 years of experience in steel pipe manufacturing
✔ 13 production lines for Φ219–Φ3500mm spiral welded pipes
✔ Annual production capacity: 400,000 tons
✔ ISO 9001, API 5L, ASTM-certified AWWA C213 FBE Coated Spiral Weld Pipes
✔ Custom FBE coatings for water, oil & gas, and industrial pipelines

2. Northwest Pipe Company (USA)

A leading water transmission pipe manufacturer, specializing in AWWA C213 and C200 spiral welded pipes.

3. American SpiralWeld Pipe Company (USA)

Produces large-diameter spiral welded pipes for municipal water and wastewater projects.

4. Jindal SAW Ltd (India)

Provides high-performance spiral pipes with fusion bonded epoxy coatings for water transmission and industrial applications.

5. Nippon Steel (Japan)

A global leader in high-strength, corrosion-resistant spiral welded pipes for marine, water, and industrial applications.

Each of these manufacturers ensures strict compliance with AWWA C213 standards, guaranteeing high durability and corrosion resistance.

AWWA C213 Spiral Weld Pipe vs Other Coated Pipes

Selecting the right coating type depends on application, cost, and durability. Below is a comparison between AWWA C213 FBE Coated Spiral Weld Pipe and other coated pipes:

Feature	AWWA C213 FBE Coated Pipe	3LPE Coated Pipe	AWWA C210 Epoxy Coated Pipe
Coating Type	Fusion Bonded Epoxy (FBE)	3-Layer Polyethylene (3LPE)	Liquid Epoxy Coating
Corrosion Resistance	High	Very High	Very High
Best Use Case	Water transmission, oil & gas pipelines	Underground and marine applications	Water, oil & gas, and wastewater pipelines
Lifespan	30-50 years	50+ years	50+ years
Chemical Resistance	Good	Excellent	Excellent
Mechanical Protection	Moderate	High	Moderate
Cost	Moderate	Expensive	Moderate

Why Choose AWWA C213 FBE Coated Spiral Weld Pipe?

✔ Excellent corrosion and chemical resistance
✔ Long service life in water, wastewater, and industrial applications
✔ Ideal for high-pressure pipelines and aggressive environments
✔ Cost-effective compared to 3LPE coatings

AWWA C213 Spiral Weld Pipe Price Per Ton in 2025

The price of AWWA C213 FBE Coated Spiral Weld Pipes varies based on factors such as pipe diameter, wall thickness, steel grade, and coating thickness. Below is an estimated pricing chart for 2025:

Wall Thickness (mm)	Steel Grade	Price Per Ton (USD)
6 – 10 mm	API 5L X42 – X65	3,800−3,800 – 3,800−5,200
12 – 18 mm	API 5L X65 – X70	4,500−4,500 – 4,500−6,500
20 – 40 mm	API 5L X70 – X80	6,000−6,000 – 6,000−8,500

Factors Affecting Price:

✔ Pipe Diameter & Wall Thickness – Larger and thicker pipes require more material.
✔ Coating Type – FBE coatings vary in cost based on thickness and project specifications.
✔ Bulk Orders – Large quantity orders receive better pricing.

Cangzhou Spiral Steel Pipes Group offers high-quality AWWA C213 FBE Coated Spiral Weld Pipes at competitive prices.

AWWA C213 FBE Coated Spiral Weld Pipe Manufacturing Process & Quality Control

How Are AWWA C213 FBE Coated Spiral Weld Pipes Manufactured?

The manufacturing process of AWWA C213 FBE Coated Spiral Weld Pipes follows strict AWWA, API 5L, ASTM A252, and GB/T9711 standards to ensure high durability, corrosion resistance, and chemical protection. Below is a step-by-step breakdown of the production process:

1. Raw Material Selection

• High-quality steel coils (API 5L, ASTM A252, GB/T9711) are carefully selected to meet chemical and mechanical composition requirements.
• The steel undergoes chemical and mechanical testing to verify yield strength, tensile strength, and impact resistance.

2. Pipe Forming & Spiral Welding

• The steel plates are rolled into a spiral shape using advanced forming machines.
• The edges are submerged arc welded (SAW) using double-sided automatic welding to ensure defect-free, high-strength weld seams.
• This welding process ensures full penetration and structural stability, making it ideal for water transmission, oil & gas, and industrial applications.

3. Hydrostatic Pressure Testing

• Each pipe undergoes high-pressure hydrostatic testing to verify leak-proof and structural reliability.

4. Ultrasonic & Radiographic Testing

• Non-destructive testing (NDT) is performed to detect internal or external defects in the weld seam.
• Ultrasonic, X-ray, and magnetic particle testing are conducted based on pipe grade and project requirements.

5. Surface Preparation

• The pipe surface is thoroughly cleaned by sandblasting or shot blasting to remove rust, scale, and contaminants.
• Proper surface preparation ensures better adhesion of the fusion bonded epoxy (FBE) coating.

6. Fusion Bonded Epoxy (FBE) Coating Application

• Heating Process: The pipe is heated to the required temperature (typically 180-250°C) to ensure proper bonding of the FBE coating.
• Electrostatic Spraying: A layer of dry epoxy powder is electrostatically sprayed onto the heated pipe surface.
• Fusing & Curing: The epoxy powder melts and fuses to the pipe surface, forming a continuous, smooth, and protective coating.
• Thickness Control: The coating thickness is measured to meet AWWA C213 standards.

7. Beveling & Cutting

• Pipes are cut into required lengths using automated machinery.
• The pipe ends are beveled for easy welding and connection.

8. Final Inspection & Packaging

• Pipes are marked, inspected, and bundled according to customer requirements.
• Each pipe is labeled with batch numbers, specifications, and manufacturer details for full traceability.

Why AWWA C213 FBE Coated Spiral Weld Pipes Are Preferred?

✔ Designed for high-pressure water and oil & gas pipeline systems
✔ Manufactured with advanced welding and coating processes
✔ High resistance to corrosion, abrasion, and chemical exposure
✔ Long-lasting performance in buried and marine environments

Cangzhou Spiral Steel Pipes Group Co., Ltd follows strict quality control procedures to ensure high-performance AWWA C213 FBE Coated Spiral Weld Pipes.

AWWA C213 FBE Coated Spiral Weld Pipe Applications & Industry Uses

Where Are AWWA C213 FBE Coated Spiral Weld Pipes Used?

AWWA C213 FBE Coated Spiral Weld Pipes are widely used in municipal water infrastructure, oil & gas pipelines, industrial projects, and environmental protection systems.

Industry	Application	Why AWWA C213 Spiral Weld Pipe?
Water Transmission	Municipal water supply, potable water pipelines	Leak-proof, corrosion-resistant, and long service life
Wastewater Systems	Sewage treatment plants, drainage pipelines	High-strength, durable, and resistant to chemical exposure
Industrial Pipelines	Power plants, chemical processing, and desalination plants	Handles high pressures and corrosive environments
Oil & Gas	Crude oil, natural gas transmission pipelines	Superior chemical resistance and long lifespan
Marine & Offshore	Coastal water transmission systems, offshore desalination plants	Resistant to seawater and extreme marine conditions

Why AWWA C213 Spiral Weld Pipes Are Ideal for Oil & Gas and Water Transmission?

✔ High resistance to chemical corrosion and environmental exposure
✔ Available in large diameters for municipal and industrial projects
✔ Cost-effective solution for long-distance transmission pipelines

Cangzhou Spiral Steel Pipes Group supplies customized AWWA C213 FBE Coated Spiral Weld Pipes for municipal water supply, oil & gas pipelines, industrial applications, and marine projects.

AWWA C213 Spiral Weld Pipe Coating & Anti-Corrosion Treatment

To ensure long-lasting performance, AWWA C213 Spiral Weld Pipes can be coated with various anti-corrosion treatments.

Coating Type	Corrosion Resistance	Best Applications
Fusion Bonded Epoxy (FBE) Coating (AWWA C213)	High	Water transmission, oil & gas pipelines
3LPE Coating	Very High	Underground pipelines, oil & gas transmission
AWWA C210 Epoxy Coating	Very High	Water, oil & gas, and industrial pipelines
Polyurethane Coating	Excellent	Industrial pipelines, sewage systems

Why Fusion Bonded Epoxy (FBE) Coating is Essential for AWWA C213 Spiral Weld Pipes?

✔ Prevents corrosion in water, oil & gas, and wastewater environments
✔ Reduces maintenance costs and extends service life
✔ Enhances resistance against chemicals, soil, and extreme temperatures

Cangzhou Spiral Steel Pipes Group provides custom coating services to meet industry-specific requirements.

Final Thoughts

For high-quality AWWA C213 FBE Coated Spiral Weld Pipes, Cangzhou Spiral Steel Pipes Group Co., Ltd is your best choice in 2025!

Need a quote or more technical details? Contact Cangzhou Spiral Steel Pipes Group today!
